Notice: Do not install anchors with tile grout. Bolthold anchors must be installed with the specified EPX2 or EPX3 special grout.
Bolthold SP58-58S Asphalt Anchors are heavy-duty anchors skillfully designed for asphalt applications. This 10″ asphalt anchor bolt is great for mounting tents, speed bumps and curbs directly to asphalt surfaces. This anchor requires a 1.5″ hole that is 10″ deep, and the use of grout to secure it into the asphalt. The thread inside the anchor should not exceed 4″. Each anchor is pre-installed with a bolt and a washer. The stainless steel finish provides enhanced corrosion resistance, making this fastener ideal for applications near salt water.
You can load the anchors at 80% of their pull rating if the object/structure stands solidly by itself. If the object applies a static pull force on the anchors just as it stands, limit the load to 20% of the pull rating.
Features:
- Anchors are mounted flush with the surface.
- A 2″ header at the top of the anchor prevents the anchor from dropping below the surface and being pulled up into the mounting plate once the bolt is tightened.
- The attached objects can be easily removed without leaving protrusions on the surface.
Required Grout:
Listed below are the approximate amounts of grout required to install one six-pack of SP58-58S asphalt anchors.
- Two six-packs of EPX2 grout. (12 oz. bags) – Each Bag Of EPX2 grout installs (0.5) SP58-58S Anchor.
- One EPX2 tub of grout. (10 lb. tub) – Each Tub Of EPX2 grout installs (10) SP58-58S Anchors.
- Six EPX3 cartridges of grout. (10 oz. tube) – Each Tube Of EPX3 grout installs (1) SP58-58S Anchor.
