- 1-3/4 HP (maximum motor HP), 11.0 Amp motor provides the power to rout smoothly through the toughest hardwoods
- Micro-fine depth adjustment ring provides precise depth adjustments in 1/64″ increments and adjusts vertically for a constant switch/cordset location
- Adjustable, tool-free steel motor cam lock makes depth adjustment and base changes quick and solid-locking
- Quick release motor latches for fast and easy motor pack removal for bit and base changes
- Integral, through-the-column dust collection collects 95% of the dust and provides superior bit visibility
- Detachable cordset offers cordset serviceability and the ability to use the same motor pack for all bases
- Sub-base concentricity gauge included to ensure bit concentricity for best-in-class accuracy
- Precision machined brass bushings and case-hardened steel guide rods provide a smooth and accurate plunge stroke
- Clear, LEXAN sub-base provides enhanced base durability, bit visibility, and accepts standard template guide bushings
- Rubber overmolded handles and low center of gravity design provide best-in-class comfort, balance, and control
- Dust-sealed switch provides durability and long switch life
- Heavy duty, precision machined, die-cast aluminum base and motor housing for durability and low tool weight
- Nickel plated motor housing for a smooth, long-lasting depth adjustment
- Right or left switch and cordset location provides the ability to have the switch in your right or left hand
- Flat top for easy bit and depth changes
- Self-releasing, long, eight slotted collets for better bit retention and eliminates frozen bits
- Five position, adjustable turret stop assists in stepped or repeated plunge cuts
- Micro-fine depth adjustment on plunge base 5/128″ per turn for precise routing in veneer and inlays
- Easy to reach plunge lever and switch for superior control while routing
Includes
- DW616M motor pack
- DW6184 fixed base
- DW6182 plunge base
- 1/4″ and 1/2″ collets
- 2 wrenches
- sub-base concentricity gauge
- vacuum adaptor
- heavy-duty kitbox
Specifications
- Amps 11.0
- Horsepower 1-3/4 HP
- No Load Speed 24,500 rpm
- Collet Diameter 1/2″, 1/4 “
- Plunge Stroke 2-1/2 “
- Depth Stop Micro-fine Ring
- Base Dimension 6 “
- Spindle Lock No
- Tool Weight 10.0 lbs
- Shipping Weight 23.6 lbs
Warranty
This DEWALT High Performance Industrial Tool comes with a warranty package that includes:
- 3 Year Limited Warranty
