HAT1020, Edwards 10 Ton Bender and Porta Power 230V, 3Ph
The Edwards 10 Ton Bender provides great flexibility to your shop.With over 300 dies available to bend pipe, tube, or square tube up to 180°,this Bender is a must have for any fabrication shop.Able to operate either Horizontally or Vertically depending on your project and with a heavy-duty rolling base, you can move the Bender out of the way when your project is complete.This Bender package includes a Portable Power Unit and is ready to PLUG IN & POWER UP.
Features:
- • Bend a wide variety of round or square tube and pipe up to 180°ls
- • Horizontal or Vertical operation provides the user flexibility
- • Over 300 standard dies available to handle your bending needs
- • Requires an Edwards Ironworker with PowerLink System or a Portable Power Unit to operate (included)
- • Easy to use Hand/Jog controls with integrated E-Stop
- • Heavy-duty rolling stand allows you to move the Radius Roller around as needed
- • 20′ quick-connect hoses for simple “plug & play” operation
- • Integrated proximity sensor and degree wheel ensure you make the right bend every time
- Built in storage on the frame keeps your Bender Dies conveniently close
Specifications:
| Country of Origin | USA |
| Tube Capacity (In.) | 2-1/2 (OD) .095 |
| Square Tube Capacity (In.) | 2 (OD) .25 |
| Bend Capacity | 180° |
| Pipe Capacity (In.) | 2 (ID) Sch 40 |
| Stroke (In.) | 14 |
| Rating (Tons) | 10 |
| Cylinder (In.) | 1-3/4 Ram |
| Height | 100.0000 |
| Length | 66.0000 |
| Weight | 1000.0000 |
| Width | 93.0000 |
