KEY FEATURES AND BENEFITS:•99.9% pure electrolytic copper coating•Molecular bond to nickel-sealed high strength steel core•Rods have a high carbon steel core and tip that provide superior strength when driving•Copper coating will not crack when bent or tear when driven•Minimum copper coating of 10 mils on rods listed to UL® 467•ERICO name, length, diameter and part number is roll-stamped within 12″ (304,8 mm) of chamfered end•UL logo and control number where applicable stamped on each rod for easy inspection after installation
99.9% pure electrolytic copper coating
Rods have a high carbon steel core and tip that provide superior strength when driving
Copper coating will not crack when bent or tear when driven
Minimum copper coating of 10 mils on rods listed to UL® 467
nVent ERICO name, length, diameter and part number is roll-stamped within 12″ (304,8 mm) of chamfered end
UL logo and control number where applicable stamped on each rod for easy inspection after installation
Molecular bond to nickel-sealed high strength steel core
Specifications
Brand Name
nVent ERICO
Sub Brand
ERICO
Item Name
Ground Rod
Type
Pointed
Nominal Size
5/8 in
Overall Length
5 ft
Coating Thickness
10 mil
Material
Carbon Steel
Finish
Electrolytic Copper
Tensile Strength
80000 lb/in²
Standards
IEC EN 62561-2
Application
For Facility Electrical Protection, Lightning Protection, Rail, Solar Power, Telecom, Utility, Wind Power
UPC
782856306078
