HEIGHT 4.25 INCH; WIDTH 2.97 INCH; DEPTH 3.65 INCH; 1 DEVICE HOLE; DEVICE HOLE LOCATION 1-ROW VERTICAL; DEVICE HOLE SIZE 22.5 MM DIA; STEEL; MATERIAL SPECIFICATION 14 GAUGE; RAL 7035 LIGHT GRAY; POLYESTER POWDER COATED OVER PHOSPHATIZED SURFACE; NEMA 12/13, IP65; WALL MOUNTING; APPROVAL UL 508, CSA, JIC EGP-1-1967, JIC EMP-1-1967; HOFFMAN[R] BRAND; CONTINUOUSLY WELDED AND GROUND SMOOTH SEAMS; WITH GROUNDING STUD
Seams continuously welded and ground smooth
Captivated cover screws thread into sealed wells
Bonding provision on cover
Grounding nut in body of enclosure
Oil-resistant gasket
Enclosures with more than one column of pushbutton holes have internal detachable hinge to hold cover open during installation
External welded-on mounting brackets for easy installation
Factory stamped 4-way pushbutton holes
22.5-mm size holes
22.5-mm size holes
Specifications
Brand Name
nVent Hoffman
Sub Brand
Hoffman
Item Name
Push Button Enclosure
Type
1-Hole, Extra Deep
Width
2.75 in
Depth
3.5 in
Height
3.25 in
NEMA Rating
NEMA 12
Material
Steel
Finish
Powder Coat
Color
Gray
For Use With
22.5 mm Push Button
Standards
UL 508A Listed, Type 12, 13, File Number E61997, cUL Listed Per CSA C22.2 No. 94, Type 12, 13, File Number E61997, NEMA/EEMAC Type 12, 13, CSA File Number 42186: Type 12, IEC 60529, IP65
Application
For Push Buttons and Switches
UPC
783510135263
