KStrong 4-Way Anchor Plate UFA30031
The KStrong® 4-Way Anchor Plate is a versatile anchor point designed for use in fall protection systems. Made from powder-coated high-strength alloy steel, it’s suitable for mounting on concrete, wood, and metal structures. It can also be used as an end point for single or multi-span horizontal lifelines.
Features & Benefits
- Designed to be fixed on concrete, wood, or metal structures with suitable fasteners.
- Can be used as an end point for single or multi-span horizontal lifeline systems.
- Powder-coated finish for enhanced durability and corrosion resistance.
Specifications
- Material: High Strength Alloy Steel
- Finish: Powder Coated Black
- Minimum Breaking Strength: 23kN
- Weight: 11.42 lbs. ± 0.04 lbs. (5.18kg ± 0.02kg)
- Standards: Meets or Exceeds ANSI Z359.18-2017 Type A
Downloads
- Techsheet
- Manual
- Declaration of Conformity
