Description:
- Magnetic line interruption switch needs a restart after a power failure
- Spindle is equipped with four heavy-duty tapered roller bearings
- Powerful single phase 1.5 HP motor
- Forward and reverse switch
- Comes complete with 1/2″ chuck with key, 3-1/2″ angle vise and safety guard
Specifications:
- DRILLING CAPACITY: 1-1/4″
- MAX. DIST. SPINDLE NOSE TO TABLE: 26-1/2″
- MAX. DIST. SPINDLE NOSE TO BASE: 47″
- SWING: 20-7/16″
- SPINDLE TAPER: R8
- SPINDLE STROKE: 5″
- DIAMETER OF COLUMN: 4-1/2″
- SPEEDS: 6 (60-1,500) RPM
- FACE MILL CAPACITY: 4″
- END MILL CAPACITY: 3/4″
- TABLE SIZE: 23″ x 7-1/2″
- MAX. TABLE TRAVEL: 14-1/2″
- CROSS TRAVEL: 6-1/4″
- SIZE OF T-SLOT ON TABLE: 1/2″
- MOTOR: 2 Amp.
- VOLTAGE: 600V, 3 phase, 60 Hz
- ASSEMBLED DIMENSIONS (LXWXH) / WEIGHT: 38″ x 37″ x 78″ / 630 lbs
- PACKAGING DIMENSIONS (LXWXH) / WEIGHT: 29-1/4″ x 33″ x 73″ / 690 lbs
