Product Description
Preformed Line Products 288811285 FIBERLIGN® ADSS DROP CABLE DEAD-ENDS = ROUND PROFILE Cable Diameter Range 0.251-0.260 in., Red.Overall length 18 in.Adapts to all ADSS Drop Designs:-Round Profile -Flat ProfileSpan Lengths up to 300’ (91.4 m) -Drop Applications (Structure to Premise)Easy Installation:No Tools RequiredConnect to Conventional Fittings-Direct Connection to 1.5″ (38.1 mm) diameter fitting-Thimble used at J-hooksTested:Elevated temperature at 140o F (60o C) tensile test -Installation Load typically 100 lbs (45.36 kg) Room temperature tensile test-Maximum Rated cable load 250 to 500 lbs (113.4 kg to 226.8 kg)
