Power Team 200 Ton Hydraulic 6″ Single Acting Load Return Cylinder R2006C

Original price was: $3,097.97.Current price is: $2,084.01.

Sale!
SKU: PTR2006C Categories: ,
Share
  • Power Team
  • HIGH-TONNAGE; LOW CYCLE; HYDRAULIC RETURN.
  • Visible indicator band alerts when stroke limit is reached; overflow port (weep hole) stroke limiter prevents piston from being overextended.
  • Alloy heat treated piston and body for reliability and strength.
  • Plated piston rod increases corrosion resistance and gives superior bearing support.
  • Order No.   : R2006C
  • Cyl. Cap. (tons)  : 200
  • Stroke (in.)  : 6
  • Oil Cap. (cu. in.) : 247.7
  • Bore Dia. (in.) : 7 1/4
  • Cylinder Effective Area (sq. in.): 41.28
  • Internal Pressure at Cap. (psi): 9;690
  • Tons at 10000 (psi) : 206.4
  • Weight (lbs.)  : 221
  • Retracted Height (in.) : 11 1/2
  • Extended Height (in.) : 17 1/2
  • Outside Dia. (in.) : 9 1/4
  • Base to Port (in.) : 1 5/8
  • Piston Rod Dia (in.): 7 1/4
  • Piston Rod Protrusion (in.):    1/8
