Home » Shop » High Tonnage » Power Team 55 Ton Hydraulic 6″ Single Acting Load Return Cylinder R556C

Power Team 55 Ton Hydraulic 6″ Single Acting Load Return Cylinder R556C

Original price was: $1,189.37.Current price is: $871.86.

Sale!
SKU: PTR556C Categories: ,
Share
  • Power Team
  • HIGH-TONNAGE; LOW CYCLE; HYDRAULIC RETURN.
  • Visible indicator band alerts when stroke limit is reached; overflow port (weep hole) stroke limiter prevents piston from being overextended.
  • Alloy heat treated piston and body for reliability and strength.
  • Plated piston rod increases corrosion resistance and gives superior bearing support.
  • Order No.  : R556C
  • Cyl. Cap. (tons) : 55
  • Stroke (in.) : 6
  • Oil Cap. (cu. in.): 66.3
  • Bore Dia. (in.): 3 3/4
  • Cylinder Effective Area (sq. in.)    11.04
  • Internal Pressure at Cap. (psi)    9;960
  • Tons at 10000 (psi): 55.2
  • Weight (lbs.) : 50
  • Retracted Height (in.): 8 15/16
  • Extended Height (in.): 14 15/16
  • Outside Dia. (in.): 5
  • Base to Port (in.): 1
  • Piston Rod Dia (in.): 3 3/4
  • Piston Rod Protrusion (in.): 1/8
