Simplex 75 Ton Spr. Ret. Single Acting 13″ Stroke Cylinder R7513

Original price was: $2,090.49.Current price is: $1,524.35.

Sale!
SKU: SIMR7513 Category:
Share
  • Simplex
  • R7513 – Cylinder
  • Single acting; spring return cylinder.
  • Stop ring for piston blow-out protection.
  • Plated piston to resist scoring and corrosion.
  • Rod wiper protects inner cylinder from dirt.
  • Single Acting; spring return cylinder.
  • Stop ring for piston blow-out protection.
  • Plated piston to resist scoring and corrosion.
  • Rod wiper protect inner cylinder from dirt.
  • Collar and piston threads for easy fixturing.
  • Model : R7513
  • Name : Cylinder
  • Order : R7513
  • Capacity : 75 ton
  • Stroke : 13.06 inch
  • Min. Height : 18.38 inch
  • Max. Pressure : 10000 psi
  • Oil Cap. Req. : 208 cu. in.
  • Weight : 130 lbs.
