07340, Stabila REC 160 RG Rotary Laser Receiver
Features:
- Laser receiver for accurately determining the beam position of rotary lasers with red or green laser diodes – even over large distances.
- Two-sided digital display for fast work – illuminated at the touch of a button.
- Visual display: Arrow symbols on the display indicate the position of the receiver relative to the reference plane of the laser.
- Acoustic guidance can be activated with beeping tones for which the volume can be set.
- Two sensitivity levels can be set for application-oriented work – “fine grade” with a sensitivity of ± 1/32 in (± 1 mm) or “coarse grade” with a sensitivity of ± 1/8 in (± 3 mm).
- Waterproof and dustproof in accordance with protection class IP 66.
- Receiver bracket for attaching to leveling rods.
- Battery status display.
- Height of receiving area: 3 1/8 in (80 mm).
- Battery life: 24 hours.
Specifications:
- Accuracy:
- Fine: ± 1 mm / 1/25 ,
- Rough: ± 3 mm / 1 / 8 ,
- Receiving spectrum: 500 nm – 680 nm
- Acoustic signal:
- Loud:> 90 dBA
- Soft: 70–90 dBA
- Batteries: 2 x 1.5 V alkaline, Mignon, AA, LR6
- Battery life: ≥ 24 hours
- Automatic switch-off: 30 minutes
- Operating temperature range: -10 °C to +50 °C / 14°F to +122°F
- Storage temperature range: -20 °C to +70 °C / -4°F to +158°F
- Protection class: IP 66
Includes:
- REC 160 RG Receiver
- Holder
- 2x AA batteries
