KStrong 100′ Galvanized Wire Cable Personnel/Material Rated Bi-directional Winch with Brake Feature and Mounting Bracket UFT531130
KStrong® 100 ft. Galvanized wire cable Personnel/Material rated bi-directional winch for confined spaces. Equipped with the Mounting plate and hardware for mounting to KStrong® Megapod Tripod (ANSI).
Features & Benefits
- Material or man lifting rescue winch.
- Comes with an Independent Reel Mode for quick and easy installation of the winch.
- Equipped with a secondary brake mechanism which reduces the dynamic load impact felt on the user in the event of a fall to less than 1800 lbs.
- Comes with preinstalled attachment point compatible with universal mounting brackets equipped on KStrong® Megapod.
- Galvanized steel wire rope of ø8/32 in (6.35 mm) & length 100 ft. (3048 cm) maximum.
- Equipped with Swivel Steel Snap Hook (PN 144 as per ANSI Z359.12-2009 gate strength 3600 lbs) as connector.
- Handle rotating mechanism for lifting or lowering.
Specifications
- Body:
- Material: Galvanized steel
- Finish: ED Coated (Black)
- Rated Load Capacity: 310 lbs (140 kg)
- Weight: 43.69 lbs. ± 0.02 lbs. (19817 gm ± 10 gm)
- Relevant Standards: Meets or Exceeds ANSI Z359.4-2013
Downloads
- Techsheet
- Declaration of Conformity
